2023 Rohrer PiXel8-RF 4MHz RF Microneedling System
The 2023 Rohrer PiXel8-RF 4MHz RF Microneedling System is an advanced FDA-cleared aesthetic platform that combines precision microneedling with 4MHz bipolar radiofrequency technology to stimulate collagen production, improve skin texture, reduce acne scars
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
2023 Rohrer PiXel8-RF 4MHz RF Microneedling System
The 2023 Rohrer PiXel8-RF 4MHz RF Microneedling System is an advanced radiofrequency microneedling platform designed to improve skin texture, firmness, elasticity, and overall skin rejuvenation. Featuring industry-leading 4 MHz bipolar RF technology, the system delivers controlled thermal energy deep into the dermis while minimizing epidermal damage. The device combines precision microneedling with radiofrequency energy to stimulate collagen remodeling and elastin production for long-lasting aesthetic improvements.
Suitable for aesthetic clinics, dermatology centers, plastic surgery practices, and medical spas, the PiXel8-RF offers customizable treatment parameters for a wide range of skin conditions and patient types.
Why Choose the Rohrer PiXel8-RF System?
Advanced 4 MHz RF Technology
Unlike conventional RF microneedling devices, the PiXel8-RF operates at a high-frequency 4 MHz bipolar RF platform that enables:
Benefits of 4 MHz Energy
- Faster tissue heating
- More precise thermal coagulation
- Enhanced collagen stimulation
- Reduced patient discomfort
- Lower risk of post-inflammatory hyperpigmentation (PIH)
- Improved treatment consistency
Precision Depth Control
The device offers adjustable needle penetration depths ranging from:
Treatment Depth Range
- 0.1 mm to 4.0 mm
This flexibility allows practitioners to treat:
- Thin facial skin
- Delicate periocular regions
- Neck laxity
- Acne scars
- Stretch marks
- Body tightening applications
Proprietary Delay Technology
The PiXel8-RF includes an advanced delay mechanism that:
- Optimizes needle heating time
- Reduces excessive radiant heat
- Minimizes epidermal trauma
- Helps reduce PIH risk
- Improves patient comfort
Facial Rejuvenation
Common Indications
- Fine lines
- Wrinkles
- Skin laxity
- Enlarged pores
- Uneven texture
- Dull skin tone
Scar Treatment Types
- Acne scars
- Surgical scars
- Traumatic scars
Body Contouring and Tightening
Treatment Areas
- Abdomen
- Arms
- Thighs
- Back
- Chest
- Neck
Skin Concerns Addressed
- Hyperpigmentation
- Crepey skin
- Stretch marks
- Uneven skin tone
System Specifications
| Specification Category | Details |
|---|---|
| Product Name | Rohrer PiXel8-RF |
| Model Year | 2023 |
| Manufacturer | Rohrer Aesthetics |
| Technology | Bipolar RF Microneedling |
| RF Frequency | 4 MHz |
| Energy Type | Radiofrequency |
| RF Configuration | Bipolar |
| Treatment Method | Fractional RF Microneedling |
| Needle Type | Disposable Microneedle Tips |
| Needle Depth Adjustment | 0.1 mm – 4.0 mm |
| Minimum Penetration Depth | 0.1 mm |
| Maximum Penetration Depth | 4.0 mm |
| Needle Insulation Options | Insulated & Non-Insulated |
| Tip Configuration 1 | 25 Pin (5 × 5) |
| Tip Configuration 2 | 49 Pin (7 × 7) |
| Tip Configuration 3 | 64 Pin (8 × 8) |
| Number of Tip Options | 6 Configurations |
| Pulse Delivery | Adjustable |
| Pulse Count | Unlimited |
| RF Duration Range | 50 – 950 ms |
| Maximum Power Output | 25 W |
| Impedance Reference | 500 Ω |
| User Interface | LCD Touchscreen |
| Screen Type | Color LCD |
| Display Size | 8-inch to 15-inch touchscreen configurations depending on version |
| Handpiece Type | Ergonomic RF Microneedling Handpiece |
| Depth Adjustment Method | Handpiece Dial Control |
| Cooling System | Air Cooling |
| Footswitch | Included |
| Treatment Modes | Fractional RF |
| Operating Voltage | 110V – 230V AC |
| Electrical Compliance | IEC 60601-1 |
| EMC Compliance | IEC 60601-1-2 |
| RF Safety Compliance | IEC 60601-2-2 |
| FDA Status | FDA Cleared |
| FDA Clearance Number | K233147 |
| Regulatory Classification | Class II Medical Device |
| Product Code | GEI / OUH |
| Intended Use | Dermatologic Procedures |
| Surgical Applications | Electrocoagulation & Hemostasis |
| Clinical Settings | Medical Spa, Dermatology, Plastic Surgery |
| Downtime | Minimal |
| Treatment Areas | Face, Neck, Chest, Arms, Abdomen, Back, Thighs |
| Consumables | Disposable RF Needle Tips |
| Skin Types | Most Fitzpatrick Skin Types |
| Treatment Goals | Tightening, Remodeling, Rejuvenation |
| Technology Platform | Fractional Micro-Needle RF |
| Cart Compatibility | Mobile Cart Optional |
| Software Interface | Guided Treatment Protocols |
| User Guidance System | Avatar-Based Interface |
| Temperature Control | Precision RF Timing System |
| PIH Reduction Feature | Enhanced Delay Technology |
| Clinical Focus | Collagen Induction Therapy (CIT) |
| Maintenance Requirement | Routine Calibration & Consumable Replacement |
