PRUFTECHNIK OPTALIGN Smart Laser Shaft Alignment
The PRUFTECHNIK OPTALIGN Smart is an advanced laser shaft alignment system designed for pumps, motors, compressors, turbines, and gearboxes, delivering precise alignment, reduced downtime, and improved machine reliability.
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
PRUFTECHNIK OPTALIGN Smart Laser Shaft Alignment
Intelligent Laser Shaft Alignment System for Precision Rotating Machinery Maintenance
The PRUFTECHNIK OPTALIGN Smart Laser Shaft Alignment System is a next-generation laser alignment solution designed to simplify and accelerate shaft alignment procedures across industrial environments. Built on advanced single-laser technology, cloud-enabled connectivity, and adaptive alignment software, OPTALIGN Smart helps maintenance teams achieve precise shaft alignment with greater speed, accuracy, and reliability.
Engineered for maintenance professionals, reliability engineers, and rotating equipment specialists, OPTALIGN Smart minimizes machine downtime, reduces vibration levels, extends bearing life, and improves overall equipment efficiency.
Why Choose PRUFTECHNIK OPTALIGN Smart?
Precision Alignment Made Simple
Misalignment remains one of the leading causes of premature bearing failures, seal damage, excessive vibration, and increased energy consumption. OPTALIGN Smart addresses these challenges through advanced laser measurement technology and intelligent software guidance.
Key Benefits
- High-precision laser shaft alignment
- Single-laser measurement technology
- Active Situational Intelligence (ASI)
- Cloud-enabled maintenance reporting
- Faster alignment procedures
- Reduced machine downtime
- Improved equipment reliability
- Extended bearing and coupling life
- Lower maintenance costs
- Easy operation for all experience levels
What Is OPTALIGN Smart?
Advanced Laser Alignment Platform
OPTALIGN Smart is a professional laser shaft alignment instrument developed by PRUFTECHNIK for precision alignment of rotating machinery.
The system combines:
- Intelligent alignment software
- Adaptive user interface
- High-performance laser sensors
- Cloud connectivity
- Digital reporting tools
- Machine train alignment capabilities
Applications
Pump Alignment
Precision Pump-to-Motor Alignment
Suitable for:
- Centrifugal pumps
- Multistage pumps
- Process pumps
- Chemical transfer pumps
- Water treatment pumps
Benefits
- Reduced seal wear
- Lower vibration
- Increased pump efficiency
Motor Alignment
Electric Motor Maintenance
Common applications include:
- Low-voltage motors
- Medium-voltage motors
- High-voltage motors
- Critical process motors
Compressor Alignment
Industrial Compressor Systems
Supports alignment of:
- Screw compressors
- Centrifugal compressors
- Reciprocating compressors
Turbine Alignment
Precision Turbomachinery Maintenance
Used in:
- Steam turbines
- Gas turbines
- Power generation facilities
Gearbox Alignment
Industrial Transmission Systems
Applicable for:
- Heavy-duty gearboxes
- Conveyor drives
- Mining equipment
- Cement plant machinery
Key Features
Single-Laser Technology
Superior Measurement Stability
Unlike traditional dual-laser systems, PRUFTECHNIK’s patented single-laser technology minimizes measurement errors caused by environmental influences.
Advantages
- Greater accuracy
- Reduced setup time
- Better repeatability
- Easier operation
Active Situational Intelligence (ASI)
Adaptive Alignment Technology
ASI automatically adapts to machine conditions and measurement situations.
Functions Include
- Dynamic filtering
- Automatic measurement optimization
- Error compensation
- Intelligent data acquisition
Benefits
- Faster measurements
- Reduced operator influence
- Increased reliability
VertiZontal Moves
Simultaneous Horizontal and Vertical Corrections
The VertiZontal Moves feature allows technicians to perform horizontal and vertical machine corrections simultaneously.
Advantages
- Reduced alignment time
- Fewer correction cycles
- Increased productivity
SensALIGN Technology
High-Performance Sensor Platform
The SensALIGN sensor provides:
- High-resolution measurements
- Automatic inclination sensing
- Wireless communication
- Exceptional repeatability
Adaptive Alignment User Interface
Simplified Workflow
The software guides users step-by-step through:
- Machine setup
- Measurement acquisition
- Alignment corrections
- Verification
- Report generation
Specifications
| Specification | Details |
|---|---|
| Product Name | PRUFTECHNIK OPTALIGN Smart |
| Product Type | Laser Shaft Alignment System |
| Alignment Technology | Single-Laser Technology |
| Measurement Principle | Laser-Based Shaft Alignment |
| Application | Rotating Machinery Alignment |
| Sensor Technology | SensALIGN Sensor |
| Laser Type | Industrial Semiconductor Laser |
| Laser Safety Class | Class 2 |
| Measurement Range | Unlimited with Extension Techniques |
| Detector Technology | High-Precision PSD Detector |
| Measurement Resolution | 0.001 mm |
| Display Resolution | 0.001 mm / 0.01 mil |
| Accuracy | ±1% Reading ±1 Digit |
| Repeatability | Extremely High |
| Measurement Modes | Continuous Sweep, Multipoint, Static |
| Minimum Rotation Angle | 40° |
| Measurement Methods | Sweep, Multipoint, Continuous |
| Machine Types | Horizontal, Vertical, Flange Mounted |
| Coupling Types | Flexible & Rigid |
| Number of Machine Trains | Multi-Coupling Supported |
| Soft Foot Detection | Yes |
| Thermal Growth Compensation | Yes |
| Target Specifications | User Configurable |
| Tolerance Evaluation | Automatic |
| Live Move Monitoring | Yes |
| Vertical Machine Alignment | Yes |
| Horizontal Machine Alignment | Yes |
| Cardan Shaft Alignment | Optional |
| Machine Train Alignment | Supported |
| Alignment Reports | Automatic |
| PDF Report Generation | Yes |
| Cloud Connectivity | Yes |
| Data Storage | Internal Database |
| Wireless Communication | Bluetooth |
| USB Connectivity | Yes |
| Wi-Fi Capability | Supported |
| Operating System | Embedded Industrial Platform |
| Display Type | High-Resolution Color Touchscreen |
| Screen Size | 8″ Class Industrial Display |
| User Interface | Graphical Guided Workflow |
| Touchscreen | Yes |
| Internal Memory | Large Capacity Storage |
| Report Export | PDF, CSV |
| Multi-Language Support | Yes |
| Automatic Sensor Detection | Yes |
| Active Situational Intelligence (ASI) | Yes |
| VertiZontal Moves | Yes |
| Live Machine Correction View | Yes |
| Measurement Quality Indicator | Yes |
| Automatic Error Filtering | Yes |
| Digital Documentation | Yes |
| Cloud Reporting | Supported |
| Battery Type | Rechargeable Lithium-Ion |
| Battery Runtime | Up to 10 Hours |
| Charger Type | AC Adapter |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Relative Humidity | Up to 95% Non-Condensing |
| Environmental Protection | Industrial Grade |
| Shock Resistance | Field Rugged |
| Housing Material | Industrial Composite |
| Sensor Protection Rating | IP65 |
| Display Unit Protection Rating | IP65 |
| Weight (Display Unit) | Approximately 1.2 kg |
| Weight (Sensor) | Lightweight Compact Design |
| CE Compliance | Yes |
| ISO Compatibility | Yes |
| Industrial Reliability Standards | Supported |
| Manufacturer | PRUFTECHNIK |
