SciAps Z-901 Portable LIBS Analyzer

Advanced Handheld LIBS Analyzer for Carbon Detection, PMI, and Alloy Verification

The SciAps Z-901 Portable LIBS Analyzer is a high-performance handheld Laser-Induced Breakdown Spectroscopy (LIBS) instrument engineered for rapid elemental analysis, positive material identification (PMI), and alloy verification. Designed specifically for industrial environments, the Z-901 combines advanced laser technology, high-resolution spectroscopy, and cloud-enabled data management in a lightweight, rugged handheld platform.

Unlike conventional handheld XRF analyzers, the SciAps Z-901 can directly measure light elements such as carbon (C), lithium (Li), beryllium (Be), boron (B), and magnesium (Mg), making it an ideal solution for carbon-equivalent analysis, stainless steel sorting, and low-alloy steel verification.

Why Choose the SciAps Z-901?

Modern industrial applications require rapid and accurate alloy identification without lengthy laboratory testing. The SciAps Z-901 addresses these requirements through:

• Instant alloy grade identification
• Carbon content determination
• Fast PMI inspections
• Weld verification
• Incoming material inspection
• Scrap metal sorting
• Aerospace alloy verification
• Petrochemical plant maintenance

Key Features

Carbon Analysis Capability

One of the most important advantages of the Z-901 is its ability to measure carbon in steels and stainless steels.

Advanced Spectrometer Technology
Single Spectrometer Configuration: Covers a wavelength range of 200 – 440 nm, allowing detection of a broad spectrum of elements.

Ergonomic and Lightweight Design
Reduced Weight: Weighs approximately 3.5 lbs (1.6 kg) with battery, enhancing portability for field operations.
Improved Heat Dissipation: Engineered for better thermal management, ensuring consistent performance in various environments.

User-Friendly Interface
Android Operating System: Provides an intuitive, app-based interface for streamlined operation.
High-Brightness Touchscreen: Features a 2.7-inch color touchscreen, readable in all lighting conditions, facilitating easy data viewing and navigation.

Versatile Analytical Capabilities
Factory Calibrations: Pre-configured to analyze 15-20 elements across various applications, including alloy analysis and environmental assessments.
Customizable Profiles: Utilizes Profile Builder software for user-defined calibrations, accommodating specific analytical requirements.

Benefits

• Differentiate L-grade stainless steels
• Verify carbon content in carbon steels
• Identify low-alloy steel grades
• Perform PMI according to industrial standards
• Reduce laboratory dependency

Laser-Induced Breakdown Spectroscopy (LIBS)

The Z-901 uses advanced LIBS technology that creates a micro-plasma on the sample surface.

Advantages

• Instant elemental analysis
• No radioactive source
• Fast measurement times
• Minimal consumables
• Low operating cost

Rugged Industrial Design

The analyzer is designed for demanding environments including:

• Refineries
• Fabrication shops
• Mining operations
• Scrap yards
• Manufacturing plants
• Power generation facilities

Android-Based Operating Platform

The intuitive Android interface provides:

• Fast touchscreen navigation
• Cloud synchronization
• Wireless communication
• User management
• Data reporting tools

Integrated Camera System

Internal Camera

• Sample positioning
• Analysis targeting

Macro Camera

• Barcode scanning
• QR code reading
• Image documentation
• Asset tracking

How LIBS Technology Works

Laser Pulse Generation

The analyzer fires a focused laser pulse onto the metal surface.

Plasma Formation

The laser vaporizes a microscopic amount of material and creates plasma.

Spectral Analysis

The emitted light spectrum is measured by the spectrometer.

Alloy Identification

The software compares results against alloy libraries and instantly identifies the material grade.

Typical Applications

Positive Material Identification (PMI)

Verify alloy compositions before installation or maintenance activities.

Industries

• Oil & Gas
• Petrochemical
• Chemical Processing
• Power Plants

Carbon Steel Verification

Measure carbon concentrations in:

• Low-alloy steels
• Carbon steels
• Stainless steels

Scrap Metal Recycling

Quickly sort:

• Stainless steels
• Tool steels
• Nickel alloys
• Titanium alloys
• Aluminum alloys
• Copper alloys

Aerospace Manufacturing

Verify critical materials before fabrication and assembly.

Quality Assurance and Quality Control

Ensure compliance with material specifications and customer requirements.

Elements Measured

Light Elements

• Lithium (Li)
• Beryllium (Be)
• Boron (B)
• Carbon (C)
• Magnesium (Mg)

Alloying Elements

• Aluminum (Al)
• Silicon (Si)
• Titanium (Ti)
• Vanadium (V)
• Chromium (Cr)
• Manganese (Mn)
• Iron (Fe)
• Cobalt (Co)
• Nickel (Ni)
• Copper (Cu)
• Zinc (Zn)
• Niobium (Nb)
• Molybdenum (Mo)
• Tungsten (W)
• Zirconium (Zr)

Supported Alloy Families

Stainless Steel

• 304
• 304L
• 316
• 316L
• 321
• 347
• Duplex
• Super Duplex

Carbon Steel

• AISI grades
• ASTM grades
• Structural steels

Low-Alloy Steel

• Cr-Mo steels
• Pressure vessel steels
• Pipeline steels

Nickel Alloys

• Inconel®
• Hastelloy®
• Monel®
• Alloy 625
• Alloy 718

Titanium Alloys

• Commercially Pure Titanium
• Ti-6Al-4V
• Aerospace titanium grades

Aluminum Alloys

• 2xxx Series
• 5xxx Series
• 6xxx Series
• 7xxx Series
