Hitachi X-MET 8000 Smart Handheld XRF
The Hitachi X-MET 8000 Smart is a portable handheld XRF analyzer designed for rapid alloy identification, PMI inspection, scrap metal sorting, manufacturing QA/QC, and precious metal analysis with reliable laboratory-grade accuracy in the field.
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
Hitachi X-MET 8000 Smart Handheld XRF Analyzer
The Hitachi X-MET 8000 Smart Handheld XRF Analyzer is a portable X-ray fluorescence (XRF) instrument designed for rapid, non-destructive elemental analysis and alloy identification. Built for industrial environments, the X-MET 8000 Smart combines high-speed performance, rugged durability, and user-friendly operation, making it an ideal solution for metal recycling, manufacturing quality control, PMI (Positive Material Identification), precious metal verification, and coating inspection applications.
Its lightweight construction, advanced Silicon Drift Detector (SDD), and intuitive touchscreen interface allow operators to obtain accurate elemental results within seconds directly in the field without laboratory testing.
Why Choose the Hitachi X-MET 8000 Smart?
Fast and Reliable Alloy Identification
The X-MET 8000 Smart delivers rapid alloy grade verification and elemental chemistry analysis for a wide range of metallic materials. Results are generated within seconds, significantly improving productivity and reducing inspection bottlenecks.
Key Benefits
- Instant alloy grade identification
- Non-destructive analysis
- Minimal operator training required
- Suitable for field and laboratory environments
- Rugged industrial construction
- Excellent repeatability and precision
- Low operating costs
- Large onboard data storage
Main Applications
Metal Recycling and Scrap Sorting
Accurately separate valuable alloys from mixed scrap streams to maximize profitability and minimize sorting errors.
Manufacturing QA/QC
Verify incoming raw materials and finished products to ensure compliance with production specifications.
Positive Material Identification (PMI)
Perform in-service material verification in refineries, petrochemical plants, power generation facilities, and fabrication workshops.
Precious Metal Analysis
Determine the composition of gold, silver, platinum, and jewelry materials quickly and accurately.
Metal Coating Inspection
Evaluate coating composition and verify plating quality without damaging the tested component.
Advanced Features
Large Area Silicon Drift Detector (SDD)
The high-performance SDD detector provides:
- Improved sensitivity
- Faster analysis speed
- Better elemental resolution
- Lower detection limits
Intuitive Touchscreen Interface
The icon-driven software simplifies operation and reduces training requirements. The large display remains readable even in outdoor environments.
Rugged Industrial Design
The analyzer is engineered for demanding industrial conditions:
- IP54 environmental protection
- Dust-resistant housing
- Splash-water protection
- MIL-STD-810G tested durability
Advanced Data Management
Users can:
- Store up to 100,000 results
- Export reports via USB
- Connect to PC software
- Utilize cloud-based data management platforms
Materials Analyzed by the X-MET 8000 Smart
Ferrous Alloys
- Carbon Steel
- Stainless Steel
- Tool Steel
- Duplex Stainless Steel
- High-Speed Steel
Non-Ferrous Alloys
- Aluminum Alloys
- Copper Alloys
- Brass
- Bronze
- Nickel Alloys
- Titanium Alloys
High-Performance Alloys
- Inconel
- Monel
- Hastelloy
- Cobalt Alloys
- Superalloys
Precious Metals
- Gold
- Silver
- Platinum
- Palladium
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Hitachi X-MET 8000 Smart |
| Instrument Type | Handheld XRF Analyzer |
| Analysis Method | X-Ray Fluorescence (XRF) |
| Detector Type | Large Area Silicon Drift Detector (SDD) |
| X-Ray Tube | 40 kV X-Ray Tube |
| X-Ray Tube Power | Up to 4 W |
| X-Ray Filters | Single Fixed Filter |
| Analytical Range | Mg to U (Magnesium to Uranium) |
| Number of Detectable Elements | Up to 40 Elements |
| Alloy Grade Library | More than 1,600 Alloy Grades |
| Calibration Method | Fundamental Parameters (FP) Standardless Calibration |
| Analysis Time | Seconds per Measurement |
| Measurement Mode | Point-and-Shoot Analysis |
| Sample Types | Metals, Alloys, Powders, Polymers, Plastics, Wood, Glass, Soil, Ores, Minerals, Liquids |
| Maximum Sample Temperature | 100°C |
| Display Type | Color Touchscreen |
| Screen Size | 4.3-inch Color LCD |
| User Interface | Icon-Based Interface |
| Integrated Camera | Optional |
| Data Storage Capacity | Up to 100,000 Results |
| Data Export | USB Flash Drive, PC |
| Cloud Connectivity | Available |
| Dust Protection | Yes |
| Water Resistance | IP54 Rated |
| Environmental Rating | NEMA 3 Equivalent |
| Military Durability Standard | MIL-STD-810G |
| Detector Protection | Window Shield |
| Battery Type | Rechargeable Lithium-Ion |
| Operating Environment | Indoor & Outdoor |
| Weight | Approximately 1.5 kg Including Battery |
| Dimensions | 93 mm × 210 mm × 272 mm |
| Spot Size | 10.7 mm × 9.4 mm |
| Optional Small Spot Collimator | Not Available on Smart Model |
| Regulatory Compliance Screening | Available |
| Precious Metals Analysis | Supported |
| Scrap Recycling Analysis | Supported |
| Manufacturing QA/QC | Supported |
| PMI Inspection | Basic Alloy Verification |
| Coating Analysis | Supported |
| Warranty | 1 Year |
| Country of Manufacture | Japan / Hitachi High-Tech Technology Platform |
| Operating Principle | Non-Destructive Elemental Analysis |
| Data Reporting | Customizable Reports |
| GPS | Not Standard on Smart Model |
| Startup Time | Rapid Startup |
| Software Updates | Supported |
| Grade Identification | Automatic |
| Pass/Fail Sorting | Supported |
| Multi-Language Interface | Supported |
| Connectivity | USB & Software Integration |
