Niton XL2 800 Smart XRF Analyzer
The Niton XL2 800 Smart XRF Analyzer is a portable handheld device designed for rapid elemental analysis and material identification. It provides accurate alloy sorting, precious metal testing, and environmental screening with laboratory-level performance in a rugged field-ready design.
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
Niton XL2 800 Smart XRF Analyzer
Advanced Handheld XRF Solution for Fast, Accurate Elemental Analysis
The Niton XL2 800 Smart XRF Analyzer is a powerful handheld X-ray fluorescence (XRF) instrument designed for rapid, non-destructive elemental analysis across a wide range of materials. Built for industrial, environmental, mining, recycling, and manufacturing applications, this device delivers fast alloy identification, precious metal testing, and compliance screening directly in the field or production site.
Engineered with high-performance detector technology and an intuitive user interface, the Niton XL2 800 provides laboratory-grade accuracy in a portable, rugged design suitable for demanding field environments.
Why Choose the Niton XL2 800 Smart XRF Analyzer?
Fast and Reliable Elemental Identification
The Niton XL2 800 delivers near-instant material analysis, allowing operators to make critical decisions on-site without waiting for laboratory results.
Key Advantages
- Instant alloy and metal identification
- Non-destructive testing
- Portable and lightweight design
- High precision measurement results
- Simple point-and-shoot operation
- Reduced laboratory dependency
- High throughput screening capability
- Rugged industrial durability
Applications of Niton XL2 800 Smart XRF Analyzer
Metal Recycling Industry
Efficient sorting of scrap metals and alloy grading to maximize material value.
Manufacturing QA/QC
Incoming material inspection and product quality verification.
Positive Material Identification (PMI)
Critical inspection in oil & gas, petrochemical, and power plant industries.
Precious Metals Analysis
Accurate testing of gold, silver, platinum, and jewelry materials.
Environmental Screening
Detection of hazardous elements in soil, coatings, and industrial waste.
Mining & Exploration
Preliminary elemental analysis for ore classification and geochemical surveys.
Core Features of the Niton XL2 800
High-Performance XRF Detector System
Equipped with advanced detector technology for fast and accurate spectral readings.
Benefits
- High sensitivity detection
- Improved spectral resolution
- Low detection limits
- Fast response time
Intuitive User Interface
Designed for ease of use in field conditions.
- Large color display
- Icon-based navigation
- Simple menu structure
- Multi-language support
Rugged Field Design
Built for harsh industrial environments.
- Shock-resistant housing
- Dust and splash protection
- Field-ready durability
- Ergonomic grip design
Smart Data Management
Efficient data recording and reporting capabilities.
- Internal memory storage
- USB data export
- PC software integration
- Custom report generation
Technical Specifications
| Category | Specification |
|---|---|
| Product Name | Niton XL2 800 Smart XRF Analyzer |
| Instrument Type | Handheld X-Ray Fluorescence (XRF) Analyzer |
| Analytical Method | Energy Dispersive XRF (EDXRF) |
| Measurement Principle | Non-destructive elemental analysis |
| Detector Type | Silicon Drift Detector (SDD) |
| X-Ray Source | Miniature X-ray tube |
| Tube Voltage Range | Up to 45 kV |
| Tube Current | Automatic control system |
| Tube Power | Optimized low-power X-ray excitation |
| Element Range | Mg to U (Magnesium to Uranium) |
| Detectable Elements | 25–40+ elements depending on calibration |
| Alloy Analysis | Yes (Ferrous & Non-Ferrous) |
| Precious Metal Mode | Yes |
| Mining Mode | Limited / Basic exploration screening |
| Soil Analysis | Yes |
| Environmental Screening | Yes |
| Measurement Time | 2–60 seconds |
| Typical Analysis Speed | 2–5 seconds for alloy ID |
| Display Type | Color LCD touchscreen |
| Screen Size | ~3.5–4.3 inch class display |
| Interface | Icon-based GUI |
| Data Storage | Internal memory (thousands of results) |
| Data Export | USB / PC connection |
| Software Support | PC-based analysis suite |
| Connectivity | USB / optional wireless (model dependent) |
| Battery Type | Rechargeable Lithium-Ion battery |
| Battery Life | Full work shift operation |
| Charging Method | External or dock charger |
| Weight | Approx. 1.5–1.7 kg |
| Dimensions | Compact handheld design (~250 × 90 × 270 mm) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Humidity Range | Up to 95% non-condensing |
| Dust Protection | Industrial grade sealing |
| Water Resistance | Splash resistant design |
| Shock Resistance | Field rugged construction |
| Safety Features | Built-in radiation safety interlock |
| Calibration Method | Fundamental Parameters (FP) |
| Grade Library | Extensive alloy library support |
| Auto Identification | Supported |
| Pass/Fail Testing | Supported |
| Calibration Standards | Factory calibrated |
