Leica TS07 Plus 5″ R500 Reflectorless Total Station
The Leica TS07 Plus 5″ R500 Reflectorless Total Station is a professional surveying instrument designed for accurate construction layout, topographic surveys, and engineering measurements with advanced reflectorless EDM technology.
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
Leica TS07 Plus 5″ R500 Reflectorless Total Station
The Leica TS07 Plus 5″ R500 Reflectorless Total Station is a professional surveying instrument designed for accurate angle and distance measurements in construction, engineering, mapping, and land surveying applications. Manufactured by Leica Geosystems, the TS07 Plus combines advanced electronic distance measurement (EDM), reflectorless technology, and intelligent digital workflows to improve field productivity and measurement reliability.
Built for demanding environments, the TS07 Plus offers precise data capture, intuitive operation, and seamless integration with Leica surveying software solutions. The system is widely used by surveyors, civil engineers, contractors, and infrastructure professionals worldwide.
What is the Leica TS07 Plus 5″ R500 Total Station?
The Leica TS07 Plus is a manual total station equipped with reflectorless EDM technology capable of measuring distances up to 500 meters without a prism. The 5″ angular accuracy version provides reliable precision for standard surveying and construction layout tasks.
The instrument enables users to perform:
- Topographic surveys
- Construction staking
- Building layout
- Elevation measurements
- Boundary surveys
- Utility mapping
- Infrastructure positioning
- As-built documentation
The TS07 Plus is part of Leica Geosystems’ FlexLine series, designed for efficiency, durability, and digital connectivity.
R500 Reflectorless EDM Technology
The integrated R500 EDM allows fast and accurate distance measurements without requiring a prism.
Advantages
- Safer remote measurements
- Faster field operations
- Access to difficult targets
- Reduced setup time
5 Arc-Second Angular Accuracy
The 5″ angular precision configuration is ideal for general construction and surveying applications requiring dependable measurement accuracy.
Leica FlexField Software
The TS07 Plus operates with Leica FlexField onboard software for intuitive workflows and simplified field operations.
Software Features
- Easy menu navigation
- Guided measurement workflows
- Data management tools
- Graphical support functions
Long Battery Life
The system is designed for extended field use with efficient power management.
Battery Benefits
- Full-day operation capability
- Reduced downtime
- Improved field productivity
Rugged Field Construction
The instrument is engineered for harsh jobsite environments.
Durability Features
- Dust-resistant housing
- Water-resistant protection
- Shock-resistant construction
- Reliable outdoor operation
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Leica Geosystems |
| Product Model | TS07 Plus |
| Series | Leica FlexLine |
| Instrument Type | Manual Total Station |
| Angular Accuracy | 5 Arc-Seconds |
| Distance Measurement Technology | EDM Reflectorless |
| Reflectorless Range | Up to 500 m |
| Prism Range | Up to 3,500 m |
| Distance Accuracy (Prism) | ±(1.5 mm + 2 ppm) |
| Distance Accuracy (Reflectorless) | ±(2 mm + 2 ppm) |
| Minimum Display | 0.1 mm |
| Angle Display Resolution | 1″ |
| Compensator Type | Dual-Axis Compensator |
| Telescope Magnification | 30x |
| Telescope Image | Erect |
| Objective Aperture | 40 mm |
| Focusing Range | 1.55 m to Infinity |
| Field of View | 1°30’ |
| Laser Pointer | Yes |
| Display Type | High-Resolution Color Display |
| Keyboard | Alphanumeric Keyboard |
| Operating System | Leica FlexField |
| Internal Memory | Yes |
| External Storage | USB Memory Support |
| Data Transfer | USB / Bluetooth |
| Wireless Connectivity | Optional Bluetooth |
| Interface Ports | USB Port |
| Guide Light | Optional EGL |
| Laser Class | Class 1 / Class 3R |
| Automatic Target Recognition | Not Included |
| Power Supply | Rechargeable Lithium-Ion Battery |
| Battery Operating Time | Up to Full Working Day |
| Operating Temperature | -20°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Dust & Water Protection | IP66 |
| Weight | Approx. 5.3 kg |
| Dimensions | Compact Portable Design |
| Tribrach Compatibility | Standard Leica Tribrach |
| Plummet Type | Laser Plummet |
| Measurement Modes | Prism / Reflectorless |
| Onboard Programs | Surveying & Layout Programs |
| Data Formats | Industry Standard Formats |
| Software Compatibility | Leica Infinity |
| Cloud Connectivity | Leica Exchange Compatible |
| User Interface | Graphical Interface |
| Construction Grade Durability | Yes |
| Calibration Support | Yes |
| Field Workflow Optimization | Yes |
| Country of Origin | Switzerland |
| Typical Industries | Surveying, Construction, Engineering |
Industries Using Leica TS07 Plus
| Industry | Application |
|---|---|
| Construction | Building layout |
| Surveying | Topographic surveys |
| Civil Engineering | Infrastructure positioning |
| Utilities | Asset mapping |
| Transportation | Road alignment |
| Mining | Site measurement |
