Pruftechnik Optalign Touch Shaft Alignment Tool

Description

Pruftechnik Optalign Touch Shaft Alignment Tool

The Pruftechnik Optalign Touch Shaft Alignment Tool is a high-precision laser shaft alignment system designed to optimize rotating machinery performance across industrial environments. Built for maintenance professionals, reliability engineers, and condition monitoring specialists, Optalign Touch delivers fast, accurate, and repeatable shaft alignment measurements while reducing machine downtime and extending equipment life.

Featuring advanced single-laser technology, cloud connectivity, touchscreen operation, and intelligent alignment software, the system simplifies complex alignment tasks for motors, pumps, compressors, turbines, gearboxes, blowers, and other rotating equipment.

Why Shaft Alignment Matters

Proper shaft alignment is essential for reliable machine operation. Misalignment can lead to:

• Premature bearing failures
• Excessive vibration
• Increased energy consumption
• Seal damage
• Coupling wear
• Unplanned downtime
• Reduced machine efficiency

Key Features

Single-Laser Measurement Technology

Unlike traditional dual-laser systems, Optalign Touch utilizes patented single-laser technology that offers:

• Higher measurement stability
• Reduced setup complexity
• Enhanced accuracy
• Easier operation in confined spaces
• Improved repeatability

Benefits of Single-Laser Technology

Adaptive Alignment Software

The intelligent alignment software automatically guides users through every step.

Features include:

• Real-time alignment corrections
• Live machine movement tracking
• Tolerance evaluation
• Automatic report generation
• Machine train alignment
• Vertical machine alignment
• Thermal growth compensation

Rugged Industrial Touchscreen

The integrated touchscreen interface offers:

• Intuitive navigation
• Color graphical displays
• Interactive alignment guidance
• Industrial-grade durability
• Glove-friendly operation

User Interface Advantages

• Easy learning curve
• Reduced training requirements
• Faster alignment completion
• Enhanced field usability

Wi-Fi and Cloud Connectivity

Optalign Touch supports modern maintenance workflows through:

• Wireless data transfer
• Cloud synchronization
• Asset management integration
• Digital reporting
• Remote data storage

Applications of Optalign Touch

Pump Alignment

Achieve precise alignment between:

• Electric motors
• Centrifugal pumps
• Positive displacement pumps
• Chemical process pumps

Motor Alignment

Suitable for:

• Low-voltage motors
• Medium-voltage motors
• High-voltage motors
• Critical production motors

Compressor Alignment

Optimize alignment of:

• Screw compressors
• Reciprocating compressors
• Centrifugal compressors

Turbine Alignment

Used for:

• Steam turbines
• Gas turbines
• Power generation systems

Gearbox Alignment

Ideal for:

• Industrial gear reducers
• Mining gearboxes
• Conveyor drives
• Heavy-duty transmission systems

Alignment Modes

Horizontal Machine Alignment

Standard alignment mode for:

• Motor-pump sets
• Compressor systems
• Industrial drive trains

Vertical Machine Alignment

Supports vertical flange-mounted equipment.

Common Applications

• Vertical pumps
• Cooling tower drives
• Vertical motors

Machine Train Alignment

Align multiple machines in a single train.

Examples:

• Turbine-Gearbox-Generator
• Motor-Gearbox-Pump
• Compressor Drive Systems

Cardan Shaft Alignment

Supports alignment of:

• Drive shafts
• Cardan shafts
• Universal joint systems

Measurement Capabilities

Continuous Sweep Measurement

Allows measurement during shaft rotation.

Benefits include:

• Faster data acquisition
• Reduced measurement time
• Improved accuracy

Specifications
