Sonatest WAVE PAUT Instrument – Advanced Phased Array Ultrasonic Testing System
The Sonatest WAVE PAUT Instrument is a next-generation phased array ultrasonic testing (PAUT) platform engineered to deliver high-performance flaw detection, corrosion mapping, weld inspection, and advanced non-destructive testing (NDT) applications. Designed for demanding industrial environments, WAVE combines powerful acquisition electronics, advanced imaging capabilities, and an intuitive touchscreen interface to help inspectors achieve faster, more accurate results.
Built upon Sonatest’s expertise in ultrasonic inspection technology, the WAVE platform supports a wide range of phased array and conventional ultrasonic testing techniques, making it suitable for industries such as oil & gas, aerospace, power generation, manufacturing, petrochemical processing, marine, and infrastructure inspection.
Why Choose the Sonatest WAVE PAUT Instrument?
The Sonatest WAVE system delivers an ideal balance between portability, performance, and advanced imaging capabilities.
Key Benefits
- High-resolution PAUT imaging
- Real-time sectorial scanning (S-Scan)
- Conventional UT and PAUT in one platform
- Fast data acquisition and processing
- Large multi-touch display
- Advanced weld inspection packages
- Corrosion mapping capabilities
- Flexible probe compatibility
- Rugged field-ready construction
- Comprehensive reporting and data management
Core Features of Sonatest WAVE
Advanced Phased Array Technology
The WAVE instrument employs advanced phased array beamforming algorithms to provide superior flaw characterization and defect sizing.
Capabilities include:
- Sectorial Scans (S-Scans)
- Linear Scans (L-Scans)
- Electronic Scanning
- Dynamic Depth Focusing
- Multi-Group Inspection
- Real-Time Imaging
Full Matrix Capture (FMC) & TFM Ready
For advanced inspections, WAVE supports modern ultrasonic imaging techniques including:
Total Focusing Method (TFM)
Provides:
- Superior defect visualization
- Enhanced sizing accuracy
- Improved Probability of Detection (POD)
- Better characterization of complex flaws
Weld Inspection Excellence
The Sonatest WAVE platform is optimized for:
Weld Quality Control
Applications include:
- Pipeline welds
- Pressure vessel welds
- Structural steel welds
- Offshore fabrication
- Nuclear plant welds
Defect Detection
Detects:
- Cracks
- Lack of fusion
- Lack of penetration
- Porosity
- Slag inclusions
- Stress corrosion cracking
Corrosion Mapping Capabilities
WAVE supports advanced corrosion inspection workflows.
Corrosion Applications
- Storage tanks
- Pipelines
- Pressure vessels
- Offshore structures
- Process equipment
Benefits
- Faster area coverage
- Thickness trending
- Corrosion profiling
- Data archiving
- Predictive maintenance support
Applications
Ultrasonic NDT inspection
Weld, forging, and casting analysis
Corrosion mapping
Aerospace and power generation maintenance
Oil and gas pipeline testing
Technical Specifications
Hardware Specifications
| Specification | Details |
|---|---|
| Product Name | Sonatest WAVE PAUT Instrument |
| Manufacturer | Sonatest Ltd. |
| Inspection Technology | Phased Array Ultrasonic Testing (PAUT) |
| Additional Technology | Conventional UT |
| Optional Technology | TOFD, FMC, TFM |
| Display Type | High-Resolution Color Touchscreen |
| Screen Technology | Capacitive Multi-Touch |
| User Interface | Touch-Based Navigation |
| Operating Modes | UT, PAUT, FMC, TFM, TOFD |
| Data Storage | Internal Solid-State Memory |
| Export Formats | Multiple Industry Formats |
| Connectivity | USB, Ethernet, Wi-Fi (depending on configuration) |
| Probe Compatibility | Sonatest and Industry Standard PA Probes |
| Wedge Compatibility | Standard and Custom Wedges |
| Battery Type | Rechargeable Lithium-Ion |
| Field Operation | Portable Handheld Unit |
| Environmental Design | Rugged Industrial Housing |
| Protection Rating | Industrial Grade Protection |
| Operating Temperature | Suitable for Industrial Environments |
| Weight | Portable Field Configuration |
| Firmware Upgradeable | Yes |
| Language Support | Multiple Languages |
| Reporting Software | Integrated |
| Calibration Tools | Built-In |
| Scan Visualization | A-Scan, B-Scan, C-Scan, S-Scan |
| Data Management | Advanced Database Support |
PAUT Performance Specifications
| Parameter | Specification |
|---|---|
| PAUT Channels | Up to 64 Active Channels* |
| Aperture Control | Dynamic |
| Beam Steering | Yes |
| Beam Focusing | Dynamic |
| Sectorial Scan Range | Wide Angular Coverage |
| Focal Law Support | Multiple Focal Laws |
| Multi-Group Operation | Yes |
| Scan Types | S-Scan, E-Scan, L-Scan |
| Real-Time Imaging | Yes |
| High-Speed Acquisition | Yes |
| Encoder Compatibility | Yes |
| Corrosion Mapping | Supported |
| Weld Inspection Packages | Supported |
| Advanced Sizing Tools | Included |
| TFM Imaging | Available |
| FMC Capture | Available |
| Data Recording | Continuous Recording |
| Analysis Tools | Comprehensive |
Imaging & Analysis Specifications
| Function | Capability |
|---|---|
| A-Scan | Real-Time |
| B-Scan | Real-Time |
| C-Scan | Real-Time |
| S-Scan | Real-Time |
| TFM Imaging | Supported |
| FMC Acquisition | Supported |
| Dynamic Depth Focusing | Yes |
| Amplitude Analysis | Yes |
| Distance Measurements | Yes |
| Sizing Algorithms | Advanced |
| Indication Classification | Supported |
| Data Replay | Full Dataset Review |
| Report Generation | Automated |
Industries Served
| Industry | Applications |
|---|---|
| Oil & Gas | Pipeline Inspection |
| Petrochemical | Vessel Inspection |
| Aerospace | Composite Testing |
| Manufacturing | Weld Inspection |
| Marine | Hull Evaluation |
| Nuclear | Safety Inspections |
| Power Generation | Component Integrity |
| Transportation | Structural Assessment |
| Construction | Steel Structure Inspection |
