Olympus Magna-Mike 8600 Precision Wall Thickness Gauge

Description

Olympus Magna-Mike 8600 Precision Wall Thickness Gauge

The Olympus Magna-Mike 8600 Precision Wall Thickness Gauge is a high-performance portable thickness measurement instrument designed for nonferrous materials. Using advanced Hall Effect magnetic technology, the device enables operators to perform fast, accurate, and non-destructive wall thickness inspections on plastic, glass, composite, aluminum, and other nonmagnetic materials.

Widely used across aerospace, packaging, automotive, laboratory, manufacturing, and quality control industries, the Magna-Mike 8600 offers repeatable thickness measurements even on curved, irregular, or hard-to-access surfaces. Its portable design, high-speed scan capability, and intelligent data logging make it one of the most trusted wall thickness gauges in industrial inspection applications.

Why Choose the Olympus Magna-Mike 8600?

Advanced Hall Effect Measurement Technology

Unlike conventional ultrasonic gauges, the Magna-Mike 8600 uses a magnetic target ball, wire, or disk together with a Hall Effect sensor to measure wall thickness from one side of the material. This method provides highly stable and repeatable readings on nonferrous products.

Fast and Accurate Thickness Inspection

The instrument supports high-speed scanning up to 60 Hz, enabling operators to inspect production parts quickly while maintaining excellent measurement precision.

Portable and Rugged Industrial Design

Built for demanding environments, the Magna-Mike 8600 features an IP67-rated enclosure, durable probes, and long battery life for continuous field operation.

Key Features

Non-Destructive Thickness Measurement

The system measures wall thickness without cutting, damaging, or disassembling the test object.

Suitable Materials

• Plastic containers
• PET bottles
• Glass products
• Composite materials
• Aluminum parts
• Rubber components
• Nonferrous industrial materials

Multiple Probe Configurations

The Magna-Mike 8600 supports several probe styles for different applications.

Available Probe Types

• Straight probe
• Right-angle probe
• Low-profile articulating probe

These probe options allow measurement access in confined or curved areas.

Replaceable Wear Caps

The probe system includes interchangeable wear caps that help extend probe life and reduce maintenance costs.

Wear Cap Options

• Standard wear cap
• Chisel tip wear cap
• Extended wear cap

Expanded Thickness Range

The Magna-Mike 8600 supports measurements up to 25.4 mm (1 inch), significantly increasing application flexibility compared to older models.

High-Speed Scan Capability

The gauge captures measurements at up to 60 readings per second, allowing rapid scanning and minimum thickness detection during production inspection.

Applications

Plastic Packaging Industry

The device is commonly used to measure:

• PET bottle wall thickness
• Plastic container corners
• Blow-molded packaging
• Thin-wall plastic products

Aerospace Industry

Ideal for inspecting:

• Composite aircraft parts
• Curved aluminum structures
• Narrow profile components
• Nonferrous aerospace assemblies

Automotive Manufacturing

Used for:

• Fuel tank thickness inspection
• Plastic component verification
• Rubber material analysis
• Quality assurance testing

Laboratory and Research Applications

The Magna-Mike 8600 is also suitable for:

• Material research
• Prototype validation
• Product development
• Quality control laboratories

Specifications

Target Ball Measurement Ranges

Magna-Mike 8600 vs Conventional Thickness Gauges
