Waygate Krautkramer USM 36 UT Flaw Detector

Description

Waygate Krautkramer USM 36 UT Flaw Detector

The Waygate Krautkramer USM 36 UT Flaw Detector is a compact and rugged ultrasonic testing device developed for professional non-destructive testing (NDT) applications. Combining trusted Krautkramer ultrasonic inspection technology with modern digital signal processing, the USM 36 provides accurate flaw detection, weld inspection, corrosion analysis, and material evaluation across a wide range of industrial sectors.

Designed for portability and dependable field operation, the USM 36 offers excellent A-scan visualization, intuitive controls, advanced calibration functions, and durable construction for inspectors working in demanding industrial environments. Its lightweight ergonomic design makes it suitable for extended inspections in oil & gas, aerospace, fabrication, power generation, automotive, and heavy manufacturing industries.

Why Choose the Waygate Krautkramer USM 36?

The Krautkramer USM 36 delivers efficient ultrasonic inspection performance while maintaining simplicity and portability for field technicians and NDT professionals.

Key Advantages

Accurate Flaw Detection

Provides dependable ultrasonic detection of cracks, inclusions, laminations, corrosion, and weld defects.

Compact Portable Design

Lightweight handheld configuration improves mobility during field inspections.

Rugged Industrial Construction

Designed to withstand demanding industrial operating conditions.

Advanced Digital Signal Processing

Enhances waveform stability and improves flaw visibility.

User-Friendly Interface

Simple menu navigation allows faster operation and reduced training requirements.

Main Applications

Weld Inspection

Ideal for detecting:

• Cracks
• Lack of fusion
• Slag inclusions
• Porosity
• Weld discontinuities

Corrosion Monitoring

Suitable for:

• Pipeline inspections
• Pressure vessel analysis
• Storage tank evaluation
• Thickness measurement applications

Manufacturing Quality Assurance

Used for inspecting:

• Forgings
• Castings
• Rolled products
• Machined industrial components

Aerospace Component Inspection

Supports inspection of:

• Aircraft structures
• Aerospace welds
• Composite materials
• Turbine components

Power Generation Industry

Applied for:

• Boiler inspections
• Turbine maintenance
• Structural integrity analysis
• Plant maintenance inspections

Key Features

Digital Ultrasonic Inspection Technology

The USM 36 uses advanced digital processing to deliver stable and accurate ultrasonic inspection performance.

Inspection Benefits

• Enhanced defect visibility
• Reduced signal noise
• Stable A-scan presentation
• Improved inspection repeatability

High-Contrast A-Scan Display

The clear industrial display improves visibility during indoor and outdoor inspections.

Display Features

• Real-time waveform display
• Adjustable brightness
• High-contrast visualization
• Optimized field readability

Portable Ergonomic Design

The compact handheld design allows inspectors to work efficiently during prolonged inspections.

Portability Advantages

• Lightweight construction
• Comfortable handling
• Easy transportation
• Reduced operator fatigue

Advanced Calibration Functions

Supports precise calibration procedures for reliable flaw detection.

Calibration Functions

• DAC
• TCG
• Distance correction
• Velocity calibration
• Automatic calibration support

Rugged Field-Ready Construction

Built for reliable operation in harsh industrial environments.

Rugged Features

• Impact-resistant housing
• Industrial protective enclosure
• Durable keypad design
• Long-term operational reliability

Specifications
