Fluke ii900 Acoustic Imager

Description

Fluke ii900 Acoustic Imager

The Fluke ii900 Acoustic Imager is an advanced industrial acoustic imaging camera designed for compressed air leak detection, gas leak identification, and partial discharge inspection. Developed by Fluke, the ii900 combines ultrasonic sensing technology with real-time visual imaging to help maintenance teams identify hidden leaks quickly and efficiently.

Engineered for predictive maintenance and industrial reliability programs, the Fluke ii900 enables technicians to reduce energy waste, improve equipment uptime, and enhance workplace safety across manufacturing plants, utilities, data centers, and industrial facilities.

What is the Fluke ii900 Acoustic Imager?

The Fluke ii900 is a handheld acoustic imaging device that uses an array of microphones to detect ultrasonic sound waves generated by leaks and electrical discharge events.

The system converts acoustic signals into visual SoundMap images displayed directly on the touchscreen, enabling users to locate issues rapidly even in noisy industrial environments.

The device is commonly used for:

• Compressed air leak detection
• Vacuum leak inspection
• Gas leak identification
• Partial discharge detection
• Electrical inspection
• Predictive maintenance programs

Key Features of the Fluke ii900

SoundMap Acoustic Imaging Technology

The ii900 overlays acoustic information onto a visible image in real time.

Benefits

• Fast leak localization
• Improved inspection accuracy
• Simplified maintenance workflows
• Reduced troubleshooting time

Features

SoundSight technology
Acoustic imaging – blended live SoundMap with visual image
Sensitivity – detects 0.005 CFM leak at 100 psi from up to 32.8′ (10 m)
Frequency range from 2 to 52 kHz
Maximum operating distance up to 230′ (70 m)
7″ (17.78 cm) 1280 x 800 LCD display with capacitive touchscreen
Ensure proper air pressure to your pneumatic equipment
Reduce leak detection time
Improve reliability in your production line
Make leak detection part of your typical maintenance routine
Train the team in a matter of minutes
Validate repairs on the spot

Applications:

Discrete Manufacturing (Automotive, Heavy Machinery, Metals, Plastics, Pulp and Paper)
Process Manufacturing (F&B, Chemical, Pharma, Glass, Cement, Pulp and Paper)
Oil and Gas
Mining
Hospitals

Large Microphone Array

The device uses multiple precision microphones to detect ultrasonic frequencies from significant distances.

Advantages

• Long-range leak detection
• High acoustic sensitivity
• Improved directional accuracy
• Effective operation in noisy facilities

LeakQ Features

• Leak size indication
• Maintenance prioritization
• Estimated energy cost impact
• Faster decision-making

Touchscreen User Interface

The high-resolution touchscreen provides intuitive navigation and real-time acoustic visualization.

Interface Features

• Adjustable frequency filtering
• Visual leak overlay
• Image capture
• Inspection data review

Applications of the Fluke ii900

Compressed Air Leak Detection

Compressed air leaks can significantly increase operational costs.

Detectable Leak Sources

• Pneumatic fittings
• Valves
• Connectors
• Air hoses
• Regulators
• Compressors

Gas Leak Detection

The ii900 helps locate industrial gas leaks safely from a distance.

Supported Gas Systems

• Nitrogen
• Compressed gases
• Vacuum systems
• Industrial process gases

Partial Discharge Inspection

The system can identify electrical discharge events before equipment failure occurs.

Detectable Electrical Issues

• Corona discharge
• Surface tracking
• Arcing
• Insulation breakdown

Predictive Maintenance Programs

The ii900 supports proactive maintenance strategies by identifying hidden failures early.

How the Fluke ii900 Works

The acoustic imager uses an array of ultrasonic microphones to capture high-frequency sound generated by leaks or electrical discharge.

The system processes these signals and creates a SoundMap overlay that visually pinpoints the sound source on the display.

This enables operators to:

• Detect leaks rapidly
• Scan large areas efficiently
• Reduce inspection time
• Minimize production interruptions

Advantages of the Fluke ii900

Faster Inspections

Large industrial systems can be scanned in minutes rather than hours.

Reduced Energy Waste

Compressed air leaks are detected before they become costly.

Improved Safety

Technicians can inspect energized electrical systems from safer distances.

Enhanced Reliability

Early detection helps prevent unplanned equipment downtime.

Technical Specifications
