Olympus EPOCH 1000i Portable Flaw Detector
The Olympus EPOCH 1000i Portable Flaw Detector is a high-performance ultrasonic testing instrument designed for accurate flaw detection, weld inspection, corrosion analysis, and industrial non-destructive testing applications.
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
Olympus EPOCH 1000i Portable Flaw Detector
Advanced Ultrasonic Flaw Detection System for Professional Industrial NDT Applications
The Olympus EPOCH 1000i Portable Flaw Detector is a high-performance ultrasonic testing instrument engineered for advanced non-destructive testing (NDT) inspections in demanding industrial environments. Designed to combine the portability of a handheld flaw detector with the functionality of a high-end desktop ultrasonic system, the EPOCH 1000i delivers exceptional inspection performance, high-speed signal processing, and advanced data management capabilities.
Built for industries that require reliable flaw detection and precise material evaluation, the EPOCH 1000i supports weld inspection, corrosion monitoring, aerospace testing, forging analysis, composite inspection, and manufacturing quality control. Its large high-resolution display, powerful digital architecture, and rugged industrial construction make it an ideal solution for field and laboratory inspections.
Weld Inspection
Ideal for detecting:
- Lack of fusion
- Cracks
- Slag inclusions
- Porosity
- Weld discontinuities
Corrosion Inspection
Suitable for:
- Pipeline inspection
- Pressure vessel analysis
- Storage tank monitoring
- Wall thickness evaluation
Aerospace Inspection
Used for:
- Aircraft structural inspection
- Composite testing
- Turbine component evaluation
- Critical aerospace parts
Features:
Adjustable pulse repetition frequency (PRF): 5 Hz to 6 kHz
Single-shot measurements in all standard modes
Tunable square wave pulser with PerfectSquare technology
Programmable analog and alarm outputs
Over 30 digital filter sets
Digital high dynamic range receiver
Large VGA Display
The instrument includes a bright, high-resolution VGA display optimized for field inspections.
Display Advantages
- High A-scan resolution
- Excellent outdoor readability
- Adjustable display settings
- Improved waveform interpretation
Advanced Inspection Software
The EPOCH 1000i supports advanced ultrasonic inspection functions.
Supported Functions
- DAC (Distance Amplitude Correction)
- DGS/AVG
- TCG (Time Corrected Gain)
- AWS weld rating
- Corrosion software
- Echo-to-echo measurements
Specifications;
| Specification Category | Details |
|---|---|
| Product Name | Olympus EPOCH 1000i Portable Flaw Detector |
| Inspection Method | Ultrasonic Testing (UT) |
| Technology Type | Digital Ultrasonic Flaw Detector |
| Display Type | High-resolution VGA color display |
| Screen Resolution | VGA resolution |
| Display Mode | A-scan |
| Frequency Range | 0.2 MHz to 30 MHz |
| Pulser Type | Square wave pulser |
| Receiver Bandwidth | Wide-band digital receiver |
| Gain Range | Wide adjustable gain |
| Dynamic Range | High dynamic range |
| Measurement Modes | Sound path, depth, projection, thickness |
| Inspection Modes | Pulse echo, dual element |
| Calibration Functions | Automatic and manual calibration |
| DAC | Supported |
| DGS/AVG | Supported |
| TCG | Supported |
| AWS Weld Rating | Supported |
| Corrosion Software | Optional |
| Echo-to-Echo Measurement | Supported |
| Gate Monitoring | Multiple adjustable gates |
| Alarm Functions | Audible and visual alarms |
| Waveform Freeze | Supported |
| Data Logging | Internal storage capability |
| Report Generation | Digital reporting support |
| Image Capture | Screenshot capability |
| File Storage | Internal memory and removable storage |
| Connectivity | USB and external interfaces |
| Probe Compatibility | Single and dual element probes |
| Pulser Repetition Frequency | Adjustable PRF |
| Battery Type | Rechargeable lithium-ion battery |
| Battery Runtime | Extended field operation |
| Housing Protection | Industrial rugged enclosure |
| Operating Environment | Indoor and outdoor industrial use |
| Weight | Portable lightweight configuration |
| Dimensions | Compact portable design |
| User Interface | Menu-driven ergonomic operation |
| Operating Temperature | Wide industrial temperature range |
| Data Transfer | USB export/import |
| Software Upgradeability | Firmware update support |
| Inspection Applications | Welds, corrosion, aerospace, manufacturing |
| Compliance Standards | Industrial UT compliance standards |
| Signal Processing | Advanced digital processing |
| Display Brightness | Adjustable high-brightness display |
| Inspection Capability | Cracks, inclusions, corrosion, laminations |
| Portability | Field-portable inspection device |
Ultrasonic Inspection Performance
Reliable Flaw Detection
The EPOCH 1000i is designed to identify both surface and subsurface discontinuities in metallic and composite materials.
Detectable Defects
- Cracks
- Porosity
- Inclusions
- Corrosion damage
- Laminations
- Delaminations
- Weld defects
Benefits for NDT Professionals
Improved Inspection Productivity
Fast setup and intuitive controls reduce inspection time and improve workflow efficiency.
Enhanced Data Accuracy
Advanced digital processing improves flaw characterization and measurement precision.
Rugged Field Reliability
Designed for dependable performance in demanding industrial inspection environments.
Advanced Reporting Capabilities
Integrated data storage and reporting simplify inspection documentation.
